Optatube 60
OptaTube 60 is simple and versatile, with performance to match its compact dimensions. A variety of mounting options means that you can deliver a range of lighting effects and implementations while maintaining a common aesthetic. High colour performance is standard, with an option for even higher specifications for colour-critical applications. Choose either the black or white option to suit your interior colour scheme
Features
Warranty: 5 years
Construction: Aluminium (extruded), Polycarbonate (PC)
Metal Finish: Powder Coated
Standard Mounting: Track-mount spotlight, suspended downlight, surface-mounted spotlight or surface-mounted downlight
Life Prediction (hrs): L80 > 76,000 (B10)
Ingress Protection: IP20
Applications
Office
Commercial
Hospitality
Retail
Technical Data
PRODUCT CODE | DIMENSIONS | Luminous Flux | POWER | Optic/Beam | Colour Temperature | Colour Rendering |
|---|---|---|---|---|---|---|
ETU60B15W940-TR | ø62 x 180 mm | 1,530 lm | 15 W | 16° | 24° | 36° | 4000K (3000K optional) | ≥ 90 | ≥ 95 |
ETU60B15W940-SS | ø62 x 180 mm | 1,530 lm | 15 W | 16° | 24° | 36° | 4000K (3000K optional) | ≥ 90 | ≥ 95 |
ETU60B15W940-SD | ø62 x 174 mm | 1,530 lm | 15 W | 16° | 24° | 36° | 4000K (3000K optional) | ≥ 90 | ≥ 95 |
ETU60B15W940-PD | ø62 x 184 mm (1.0 m suspension) | 1,530 lm | 15 W | 16° | 24° | 36° | 4000K (3000K optional) | ≥ 90 | ≥ 95 |
Additional Images
Resources
Data Sheet
Installation Sheet
IES Files
SDoC
